Market data into spreadsheet
https://www.alphavantage.co/spreadsheets/. data can be shown with flask
GitHub - birdhouses/ai-trader python + open AI
GitHub - birdhouses/trading212: Get insights in your trading212 dividend payouts
Copilot answers APIdog to scrap the data from Tradingview
To use Apidog for generating a schema from TradingView's screener database, you would need to follow these steps. However, note that scraping TradingView's data directly may violate their terms of service, so it's always better to use their official API if available. Here's a general guide for schema generation using Apidog:
Apidog supports schema generation from JSON or database tables. Here's how you can proceed:
Extract JSON Data:
.json file.Generate Schema:
Connect to Database:
Generate Schema:
Let me know if you'd like further clarification! 😊
Python Library "TradingView_screener"
https://shner-elmo.github.io/TradingView-Screener/3.0.0/tradingview_screener.html#quickstart
GitHub:
https://github.com/shner-elmo/TradingView-Screener
It is handy to have an online SQL viewer to look at the contents of the database files.
https://beta.sqliteviewer.app/2025-08-17.db/table/stock_data
Copilot suggested python codes to write a data file to Google sheet.
Here’s a concise guide to storing a file's data into a Google Sheet using Python. This involves enabling the Google Sheets API, authenticating, and writing data to the sheet.
credentials.json file for authentication.google-auth, google-auth-oauthlib, google-auth-httplib2, and gspread.import gspread
from google.oauth2.service_account import Credentials
# Authenticate using the credentials.json file
scope = ["https://spreadsheets.google.com/feeds", "https://www.googleapis.com/auth/drive"]
creds = Credentials.from_service_account_file("credentials.json", scopes=scope)
client = gspread.authorize(creds)
# Open the Google Sheet by name
sheet = client.open("Your Google Sheet Name").sheet1
# Example: Writing data to the sheet
data = [["Name", "Age", "City"], ["Alice", 30, "San Francisco"], ["Bob", 25, "New York"]]
for row in data:
sheet.append_row(row)
print("Data successfully written to Google Sheet!")
import csv
import gspread
from google.oauth2.service_account import Credentials
# Authenticate using the credentials.json file
scope = ["https://spreadsheets.google.com/feeds", "https://www.googleapis.com/auth/drive"]
creds = Credentials.from_service_account_file("credentials.json", scopes=scope)
client = gspread.authorize(creds)
# Open the Google Sheet by name
sheet = client.open("Your Google Sheet Name").sheet1
# Read data from a CSV file and write to the sheet
with open("your_file.csv", "r") as file:
reader = csv.reader(file)
for row in reader:
sheet.append_row(row)
print("File data successfully written to Google Sheet!")
import gspread
from google.oauth2.service_account import Credentials
# Authenticate using the credentials.json file
scope = ["https://spreadsheets.google.com/feeds", "https://www.googleapis.com/auth/drive"]
creds = Credentials.from_service_account_file("credentials.json", scopes=scope)
client = gspread.authorize(creds)
# Open the Google Sheet by name
sheet = client.open("Your Google Sheet Name").sheet1
# Example: Writing dictionary data to the sheet
data = [{"Name": "Alice", "Age": 30, "City": "San Francisco"},
{"Name": "Bob", "Age": 25, "City": "New York"}]
# Write headers
sheet.append_row(list(data[0].keys()))
# Write rows
for entry in data:
sheet.append_row(list(entry.values()))
print("Dictionary data successfully written to Google Sheet!")
"Your Google Sheet Name" with the actual name of your Google Sheet.credentials.json file is downloaded from your Google Cloud Console and placed in the same directory as your script.pip install gspread google-auth google-auth-oauthlib google-auth-httplib2
Let me know if you need further clarification or help! 😊
Indian guy stockanalysis
MCP codes only for India market
his GitHub depository , not much description over there
https://github.com/varun-g-12/StockAnalysisMCP
Python Library "TradingView_scrapper" live example
Saved 3 files:- 52wks high , all time highs, and high gainers in excel formats everyday.
then analyze the patterns, next things I would do is to save the files into my Google sheets.
data scrapped from this TradingView page:
https://www.tradingview.com/markets/stocks-usa/market-movers-52wk-high/
Original
my codes:
from urllib.request import urlopen
from bs4 import BeautifulSoup
import pandas as pd
from datetime import date
import os
from urllib.error import HTTPError
def tradingviewScrapper():
urls = [
'https://www.tradingview.com/markets/stocks-usa/market-movers-52wk-high/',
'https://www.tradingview.com/markets/stocks-usa/market-movers-ath/',
'https://www.tradingview.com/markets/stocks-usa/market-movers-gainers/'
]
root_path = r'/Users/dl/Documents/codes/tradings/'
print(f"Saving files to: {root_path}")
os.makedirs(root_path, exist_ok=True)
for url in urls:
try:
# Content retrieval
page = urlopen(url)
html = page.read().decode("utf-8")
# Create BeautifulSoup object
soup = BeautifulSoup(html, "html.parser")
rows = soup.find_all('tr')
parts = url.split('market-movers-')
typeurl = parts[1]
today = date.today().strftime('%y-%m-%d')
data = []
# Loop through each line and get data from element <td>
for row in rows:
# Get all <td> elements in a line
cells = row.find_all('td')
# Get the text content from each cell and add it to the data list
row_data = [cell.text.strip() for cell in cells]
data.append(row_data)
th_elements = rows[0].find_all('th')
headers = [th.text.strip() for th in th_elements]
# Create DataFrame from data list
df = pd.DataFrame(data, columns=headers)
filename = f'Data_{str(typeurl)}_{str(today)}.xlsx'
excel_path = os.path.join(root_path, filename)
print(f"Saving Excel to: {excel_path}")
# Ensure the parent directory exists
os.makedirs(os.path.dirname(excel_path), exist_ok=True)
df.to_excel(excel_path, index=False)
print(f'Data {url} successfully discraping.')
except Exception as e:
print(f"Error saving file: {e}")
tradingviewScrapper()
----------------------------------------------------------------------------------------------------------------------------
SD Card Pin Mapping on ESP32-CAM
The ESP32-CAM uses specific GPIO pins for interfacing with the SD card. These pins are shared with other peripherals, limiting their availability for general use. The SD card connections are as follows:
Key Notes:
GPIO4 is connected to the onboard flash LED, which may cause it to flash during SD card operations.
GPIO12 must be LOW during boot to avoid issues with the ESP32's boot process.
SD Card Modes and Available GPIOs
The SD card can operate in two modes: 4-bit mode and 1-bit mode. Each mode affects the availability of GPIOs.
4-Bit Mode
In 4-bit mode, all six GPIOs (2, 4, 12, 13, 14, 15) are used for SD card communication. This leaves only GPIO16 available for other purposes.
1-Bit Mode
In 1-bit mode, the SD card uses fewer pins, freeing up GPIO12 and GPIO13 for other uses. The configuration for 1-bit mode is as follows:
This mode reduces data transfer speed but provides additional GPIOs for peripherals.
Managing GPIO4 (Flash LED)
To prevent the flash LED from interfering with SD card operations, you can initialize it manually:
Caution: Avoid keeping the flash LED on for extended periods, as it lacks a current-limiting resistor and may overheat.
Additional Tips for GPIO Management
GPIO16 is always available but may have limitations depending on your board's configuration.
If more GPIOs are needed, consider using an I2C GPIO expander like the MCP23017. This allows you to add multiple GPIOs while using only two pins (SDA and SCL).
Example of Using MCP23017
This approach can significantly expand the number of GPIOs available for your project.
Conclusion
The ESP32-CAM's GPIOs are heavily utilized by the camera and SD card. By switching to 1-bit mode, you can free up GPIO12 and GPIO13 for additional functionality. For more extensive GPIO requirements, consider using an I2C GPIO expander. These strategies allow you to maximize the ESP32-CAM's capabilities while maintaining SD card functionality.
SD gpio pins usage:-
https://stackoverflow.com/questions/73178340/esp32-cam-sd-and-camera-use-up-all-the-pins
more precise desc about sd 1 bit mode:
https://dr-mntn.net/2021/02/using-the-sd-card-in-1-bit-mode-on-the-esp32-cam-from-ai-thinker
https://github.com/alanesq/esp32cam-demo.
GPIO2 pin is used as a bootstrapping pin, and should be low to enter UART download mode. One way to do this is to connect GPIO0 and GPIO2 using a jumper, and then the auto-reset circuit on most development boards will pull GPIO2 low along with GPIO0, when entering download mode.
spi flash
The ESP32-CAM features only one SPI (VSPI) in slave and master modes. It also supports the general-purpose SPI features listed below:
https://microcontrollerslab.com/esp32-cam-ai-thinker-pinout-gpio-pins-features-how-to-program/#google_vignette. several articles about the camera
https://gitmemories.com/index.php/jameszah/ESP32-CAM-RocketCam
hx-esp32-cam-fpv. spectacular air video
https://github.com/rolly46/hx-esp32-cam-fpv
ftp server
https://github.com/mtnbkr88/ESP32_FTPServer. for esp32 cam
https://github.com/nopnop2002/esp-idf-ftpServer
https://github.com/espressif/esp-idf. building environment and development software. python based
installation procedures:-
mkdir esp, cd esp,
git clone https://github.com/espressif/esp-idf
cd esp-idf
git submodule update --init --recursive
./install.sh
./export.sh
idf.py build or
idf.py main.py or
idf.py menuconfig
upload flash
idf.py -p /dev/ttyUSB0 -b 115200 flash
instructions to run build availabel
https://www.xda-developers.com/how-use-ftp-mac/. ftp replaced with smb or sftp
SD CARD
https://github.com/s60sc/ESP32-CAM_MJPEG2SD. pretty new project
https://forum.arduino.cc/t/esp32s-can-t-detect-mount-microsd-card-fix/914266. FIX
https://github.com/espressif/arduino-esp32/issues/4680
// Libraries for SD card
#include "FS.h"
#include <SD.h>
//#include "mySD.h"
#include <SPI.h>
// Define CS pin for the SD card module
#define SD_MISO 2
#define SD_MOSI 15
#define SD_SCLK 14
#define SD_CS 13
SPIClass sdSPI(VSPI);
String dataMessage;
void setup() {
// Start serial communication for debugging purposes
Serial.begin(115200);
// Initialize SD card
//SD.begin(SD_CS);
sdSPI.begin(SD_SCLK, SD_MISO, SD_MOSI, SD_CS);
if(!SD.begin(SD_CS, sdSPI)) {
Serial.println("Card Mount Failed");
return;
}
Serial.println("1");
uint8_t cardType = SD.cardType();
if(cardType == CARD_NONE) {
Serial.println("No SD card attached");
return;
}
Serial.println("Initializing SD card...");
if (!SD.begin(SD_CS)) {
Serial.println("ERROR - SD card initialization failed!");
return; // init failed
}
Serial.println("2");
// If the data.txt file doesn't exist
// Create a file on the SD card and write the data labels
File file = SD.open("/data1.txt");
if(!file) {
Serial.println("File doens't exist");
Serial.println("Creating file...");
writeFile(SD, "/data1.txt", "Reading ID, Date, Hour, Temperature \r\n");
}
else {
Serial.println("File already exists");
}
file.close();
logSDCard();
}
void loop() {
// The ESP32 will be in deep sleep
// it never reaches the loop()
}
// Write the sensor readings on the SD card
void logSDCard() {
//dataMessage = String(readingID) + "," + String(dayStamp) + "," + String(timeStamp) + "," +
// String(temperature) + "\r\n";
dataMessage = "Hello World \n";
Serial.print("Save data: ");
Serial.println(dataMessage);
appendFile(SD, "/data1.txt", dataMessage.c_str());
}
// Write to the SD card (DON'T MODIFY THIS FUNCTION)
void writeFile(fs::FS &fs, const char * path, const char * message) {
Serial.printf("Writing file: %s\n", path);
File file = fs.open(path, FILE_WRITE);
if(!file) {
Serial.println("Failed to open file for writing");
return;
}
if(file.print(message)) {
Serial.println("File written");
} else {
Serial.println("Write failed");
}
file.close();
}
// Append data to the SD card (DON'T MODIFY THIS FUNCTION)
void appendFile(fs::FS &fs, const char * path, const char * message) {
Serial.printf("Appending to file: %s\n", path);
File file = fs.open(path, FILE_APPEND);
if(!file) {
Serial.println("Failed to open file for appending");
return;
}
if(file.print(message)) {
Serial.println("Message appended");
} else {
Serial.println("Append failed");
}
file.close();
}
https://randomnerdtutorials.com/esp32-spi-communication-arduino/. esp32 cam spi pinouts
| SPI | MOSI | MISO | SCLK | CS |
| VSPI | GPIO 23 | GPIO 19 | GPIO 18 | GPIO 5 |
| HSPI | GPIO 13 | GPIO 12 | GPIO 14 | GPIO 15 |
